This Easy9 product is a modular and reliable switch. This one is used for control (opening and closing of circuits under load). This product is also used for disconnection of on-load electrical circuits already protected against overload and short-circuits. It has a position contact indication suitable for industrial isolation according to IEC 60947-3 standard. It is a 2P device with 40A rated current. Electrical endurance goes up to 10000 cycles, and mechanical endurance goes up to 20000 cycles. The Ue rated operational voltage is 415VAC. It can be mounted on DIN rail for modular installation. Its width is 4 pitches of 9mm. The dimensions are (W) 36mm x (H) 81mm x (D) 77.5mm. The product weight is 255g. The degree of protection is IP20. The operating temperature is -5°C to 55°C. The storage temperature is -25°C to 85 °C. This product complies with IEC 60947-3 standard.
SCHNEIDER EASY ISOLATOR 2P 40A (EZ9S66240)
| Range | Easy9 |
|---|---|
| Product or component type | Switch |
| Device short name | Easy9 switch |
| Switch application | Distribution |
| Poles | 2P |
| [Ie] rated operational current | 40 A at 415 V 50/60 Hz |
|---|---|
| [Ue] rated operational voltage | 415 V AC 50/60 Hz |
| [Icm] rated short-circuit making capacity | 0.6 kA |
| [Icw] rated short-time withstand current | 0.48 kA during 0.3 s at -5…55 °C |
| 9 mm pitches | 4 |
| height | 81 mm |
| Width | 36 mm |
| Depth | 77.5 mm |
| Net weight | 0.255 kg |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles |
| Connections – terminals | Tunnel type terminal (top or bottom) 1…35 mm² rigid Tunnel type terminal (top or bottom) 1…25 mm² flexible |
| Tightening torque | 3.5 N.m |
| IP degree of protection | IP20 conforming to IEC 60947-3 |
|---|---|
| ambient air temperature for operation | -5…55 °C |
| Ambient air temperature for storage | -25…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8 cm |
| Package 1 Width | 4 cm |
| Package 1 Length | 9 cm |
| Package 1 Weight | 0.173 kg |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 72 |
| Package 2 Height | 30 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 12.456 kg |
