| Residual Current Circuit Breakers provide protection against earth leakage fault. They ensure safety of human life in case of earth leakage fault and protection against electric shock. |
L&T EXORA RCCB 2P 63AMP 30MA
| Discount Percentage |
|
Between 0-10 % |
| Operating Temperature Range |
|
-5°C to +55°C |
| Electrical life (Operating Cylces) |
|
10000 |
| Tightening Torque |
|
4Nm |
| Termination capacity |
|
50 Sq. mm (Rigid) 35 Sq. mm (Flexible) |
| Mechanical Life (Operating Cycles) |
|
20000 |
| No. of Poles |
|
DP |
| Conformance to standards |
|
IS 12640-1 |
| IEC 61008-1 |
| Rated Insulation Voltage Ui (V) |
|
500V |
| Rated Frequency |
|
50Hz |
| Rated Residual Making & Breaking capacity |
|
1 kA |
| Rated Impulse Voltage |
|
4kV |
| Rated Conditional SC Current |
|
10 kA |
| Current Rating |
|
40A |
| Rated Operational voltage (Ue) |
|
240V |
| Conformance to Standards |
|
IS 12640-1 IEC 61008-1 |
| Sensitivity |
|
30mA |
| Length(mm) |
|
77.1 |
| Height(mm) |
|
83 |
| Breadth(mm) |
|
35 |
